Abɔnten so Nneɛma a Wɔde Kata So

Wo Professional Abɔnten so Coating Supplier

Octal Pipe yɛ adwumayɛfoɔ ne wɔn a wɔaka abom a wɔde ngo a wɔde yɛ nneɛma ne mfiridwuma mu dadeɛ ano aduru a ɛwɔ China. Yɛwɔ osuahu pii wɔ nneɛma a wɔde ma, kyekyɛ, ne nneɛma a wɔyɛ mu, yɛyɛ yɛn ho titiriw wɔ dade nneɛma ahorow pii a yɛde ma ma ngo & gas, ahoɔden, ne mfiridwuma mu.

Nea Enti a Wopaw Yɛn

Nneɛma a Ɛyɛ Paara a Ɛkorɔn

Wɔsɔ yɛn dade nsu afiri no hwɛ denneennen na edi amanaman ntam gyinapɛn ahorow so, na ɛhwɛ hu sɛ ɛbɛtra hɔ akyɛ a ɛso bi nni, ɛko tia nsɛe, na ɛyɛ adwuma wɔ tebea horow a emu yɛ den mu.

Adansedi nkrataa

Wɔde nneɛma biara a wɔde hwehwɛ nneɛma mu nyinaa, mill adansedi nkrataa, ne amanaman ntam gyinapɛn te sɛ API, ASTM, ASME, EN, ne ISO a wodi so na ɛhyɛ akyi.

Bo a Wɔbɔ a Wɔde Si Akan

Yɛde dade paipu a ɛyɛ fɛ-grade ma wɔ ɛka a ɛfata mu, yɛma bo a ɛsom no yɛ papa denam nneɛma a wɔyɛ ne nneɛma a wɔde ma no sohwɛ a etu mpɔn a yɛrensɛe ne su.

Fast & Ahotoso a Wɔde Kɔma

Yɛde po so nneɛma ho nhyehyɛe a etu mpɔn ne wiase nyinaa nkitahodi di dwuma, yɛhwɛ hu sɛ wɔde dade nsu afiri bɛkɔ po so wɔ bere a ɛsɛ mu, na yɛtew akyɛde so na yɛma wo mfiridwuma dwumadi ahorow no kɔ so yɛ nea wɔahyɛ da ayɛ.

FBE Coating Pipe a Wɔde Kata Nneɛma So

FBE Coated Steel Pipe yɛ dadeɛ paipu bi a wɔde epoxy resin (FBE) akata so, a wɔde di dwuma kɛseɛ wɔ nnwuma te sɛ ngo, gas, nsuo, ne nsuo anaa gas akwantuo nhama foforɔ mu. Wɔde FBE a wɔde kata so no di dwuma denam dade paipu no ani a wɔde epoxy resin kata so na afei wɔde ɔhyew so sa no ma ɛyɛ ahobammɔ a emu yɛ den a ɛma paipu no tumi gyina nsɛe ano no so. Saa ade a wɔde kata so yi siw nsɛe a efi nneɛma a atwa yɛn ho ahyia a ɛwɔ akyi te sɛ nsu, asase, ne nkyene mu ba no ano yiye, na ɛma paipu no nkwa nna kyɛ kɛse.
● Nhyehyɛe: Fusion Bonded Epoxy (FBE) a ɛwɔ ɔfa biako-layer .
● Gyinapɛn: ISO 21809-2, AWWA C213, CSA Z245.20
● Pipe Range: 1⁄2′′ – 48′′ (amane kwan so kosi 60′′)
● Nneɛma a wɔde kata so no mu duru: 250 – 500 μm
● Adwumayɛ Temp: -30 digrii kosi +95 digrii

Gyinapɛn & Nsɛm a Wɔakyerɛkyerɛ Mu

● ISO 21809-2 – FBE a wɔde di dwuma wɔ adwumayɛbea ma nsu afiri a wɔasie anaa wɔde ahyɛ nsu ase
● AWWA C213 – FBE a wɔde kata nsuo nhama so
● CSA Z245.20 – Fusion-bonded epoxy a wɔde yɛ dade paipu
● NACE SP0102 – Nneɛma a wɔde di dwuma ne nhwehwɛmu ho nneyɛe
● Pipe Range: Ɛnyɛ den, ERW, LSAW, SSAW

● OD: 1⁄2′′ – 48′′ (a wɔahyɛ da ayɛ kosi 60′′)

● Nneɛma a wɔde kata so no mu duru: 250 – 500 μm

● Adwumayɛ mu Ɔhyew: -30 digrii kosi +95 digrii

FBE Coating Adeyɛ a Wɔyɛ

Ahosiesie a Wɔyɛ wɔ Asase So

Abrasive blasting kɔ Sa 21⁄2, anchor profile 50-100 μm

Ɔhyew a wɔde ma

Induction anaa fononoo mu ɔhyew a ɛkɔ 200–250 degree

Powder a Wɔde Di Dwuma

Electrostatic a wɔde petepete epoxy powder mu

Fusion & Curing a Wɔde Yɛ Adwuma

Epoxy no nwene, ɛyɛ crosslinks, ɛde nnuru bata dade ho

Cooling & Nhwehwɛmu a Wɔyɛ

Controlled cooling, thickness checks, nnapɔnna sɔhwɛ

FBE Coating Pipe a wɔawie no mu duru a ɛba fam koraa

Pipe Sizes (Wɔakyerɛ Abɔnten Daimeter) .	Min Coating Thick Chart wɔ (MM) mu.
Ennu anaasɛ ɛne 10 3 /4 (273.1 MM) yɛ pɛ .	2.5
32 (813.0 MM) na ɛwɔ hɔ.	3.3
12 3 /4 ( 323.9 MM) kɔsi Ɛnnu anaa ɛne 18 (457 MM) yɛ pɛ .	2.8
20 (508.0 MM) kosi Nea ennu anaasɛ ɛne 0 (762 MM) yɛ pɛ .	3

Agyapadeɛ	Ahwehwɛde
Nsuo a Ɛwɔ Mu	0.5%
Muduro	1.2 ~ 1.8g/cm3 na ɛwɔ hɔ
Nsusuwii mu Nsɛm a Wɔde Ka Ho	0.6993 m2/kg wɔ mm biara mu (134.6 ft2/lb wɔ mil biara mu)
Wɔ Sieve so	150μm powder wɔ sieve so Ennu anaasɛ ɛyɛ pɛ 3% , 250μm powder wɔ sieve so Ennu anaasɛ ɛyɛ pɛ 0.2% .
Nneɛma nketenkete no kɛse	Ɛsõ sen 250um 0.2% . Ɛsõ sen 150um 3.0% .
Sini mu Nsusuwii	a.Wɔ FBE Nhyehyɛe mu: 300-400 μm (12-16 mils) . b.Sɛ́ primer wɔ 3-layer PE anaa PP nhyehyɛe mu: 150-300 microns (6-12 mils) .
Adwumayɛ Temp. Dodoɔ	-73oC (-100 digrii F) kosi digrii 110 (230 digrii F) .
Ɔhyew ho nneɛma	ΔH Ɛkɛsene anaasɛ ɛyɛ pɛ 45J/g , Tg2 Kɛseɛ anaasɛ ɛyɛ pɛ 95 degree

3PE ne FBE Coating Nsonsonoe

Nneɛma a wɔde yɛ 3PE ne FBE coating pipes no nya wɔn adwumayɛ ho nsɛnkyerɛnne so nkɛntɛnso, a ɛsɛ sɛ wɔsɔ hwɛ sɛnea ɛyɛ adwuma.

sɔhwɛ	FBE Nneɛma a Wɔde Kata So	3PE Nneɛma a wɔde kata so
Ahoɔden a Ɛbata Ho	Ɛboro anaasɛ ɛne no yɛ pɛ 10 MPa (ASTM D4541) .	Ɛboro anaasɛ ɛyɛ pɛ 15 MPa (ISO 4624) .
Nkɛntɛnso a Wɔko tia	1.5 J (ISO 6272) na ɛwɔ hɔ.	25 J (ISO 6272) Nsɛm a wɔahyehyɛ .
Katolekfo a Wɔpaapae Wɔn Ho	Ennu anaasɛ ɛne no yɛ pɛ 8 mm (48h, ASTM G8) .	Ennu mm 5 (48h, ISO 15741) anaasɛ ɛne no yɛ pɛ .
Nsuo a Ɛtumi Fa Mu	0.5–1.0 g/m2/da biara	<0.1 g/m²/day
UV a Ɛko Tia	Ohia (ɛhwehwɛ sɛ wɔde aduru a wɔde kata soro na ama owia hann) .	Ɛyɛ papa (PE layer siw 99% UV ano) .

Company Honor a Wɔde Di Dwuma

FAQ

Asɛmmisa: So wo nneɛma no du amanaman ntam gyinapɛn ho ?

A: Yɛn nneɛma wɔ pass CE, BV, ISO ne akodi adansedi krataa, na akontaabu nyinaa kyerɛ sɛ ɛkorɔn sen gyinapɛn, wubetumi ate nka sɛ wowɔ ahofadi sɛ wobɛma yɛahu ɔman gyinapɛn a wohwehwɛe, yɛbɛhwɛ anaasɛ yɛbɛsɔ ahwɛ ama wo.

Asɛmmisa: Ɔsom bɛn na wode ma ?

A: Sɛ́ adwumayɛbea a wɔyɛ nneɛma no, yɛde paipu nneɛma, paipu fittings, package ne po so hyɛn ma; sɛ́ adwumayɛfo a wɔde afotu ma adwumakuw no yɛde adwumayɛ ho afotu, paipu nhyehyɛe ano aduru ne nhyehyɛe ho nyansahyɛ ma; as an engineering focused enterprise , yɛsan nso de pipeline contractor service ne pipe repair service, nso betumi ama free maintance akwankyerɛ.

Asɛmmisa: So woboa OEM / ODM som?

A: Yiw, yɛde customization ma wɔ nneɛma, specification, logo, package , nkitahodi akwan andothers. Saa bere yi nyinaa, yɛn adwumayɛfo kuw no betumi de ano aduru nyansahyɛ ama wo nnwuma a wɔakyerɛ no, yɛwɔ successfull nsɛm a ɛfa saa ɔsom no ho.

Asɛmmisa: Dɛn ne wo sikatua ho nhyehyɛe?

A: T/T anaa L/C wɔ aniwa so.

Asɛmmisa: Wobɛyɛ dɛn ahwɛ ahu sɛ nneɛma a wode mae no fata?

A: Yɛde anigye ma adetɔfo nyinaa akwaaba yɛ nsrahwɛ wɔ yɛn adwumakuw no mu na wohu yɛn nneɛma wɔ ani so, yebetumi nso de sɔhwɛ a emu yɛ den ama sɛnea adetɔfo hwehwɛ ansa na wɔakra. Saa bere yi nyinaa, ansa na wɔayɛ no kɛse no, yebetumi asoma nhwɛsode ahorow ama adetɔfo ma wɔayɛ wɔn ankasa sɔhwɛ ahorow de afata nneɛma no.

Sɛ́ abɔnten so ade a wɔde kata so a wɔyɛ ne wɔn a wɔde ma wɔ China no mu biako no, yɛde anigye ma wo akwaaba sɛ tɔ abɔnten so aduru a ɛkorɔn-grade a wɔtɔn wɔ ha fi yɛn adwumayɛbea hɔ. Sɛ wopɛ ɔsom a wɔahyɛ da ayɛ a, di yɛn ho nkɔmmɔ mprempren.
